Our extra heavy duty large pallet forks are rated for 6,000 lbs. lift. This extremely heavy-duty large pallet fork increases the lift capacity of larger skid steers by using a see-through oversize frame. It is exceptionally durable for heavy use because to the quick attach area and the heavily reinforced brick guard. The typical tine dimensions are 48″ x 1.75″ (60″ and 72″ are also available). To satisfy the need for lifting equipment on the job site, these large pallet forks have an exceptionally wide and tall frame, are serial numbered, and have lifting capacities in pounds and kilograms. The broad back rest of this model offers a larger surface to handle unstable loads, which is why it is frequently employed in landscaping and nursery work. When comparing large pallet forks, it’s important to consider the rail that each set of forks hangs on. Some businesses build the rail out of two or three pieces of metal or use bent channel. For increased safety and durability, Melecio Attachments Inc. only employs rails that are machined from a single solid piece of bar stock. For a class 2 fork, this unit’s rail is the biggest and heaviest rail we have to offer.
Features:
• Frame Capacity 6000 Lb
• Large frame and Backrest, especially
• 48 x 4 x 1.75 tin
• Actions from both sides
• 500 LB
• Compatible with all universal skid steer couplers
• strong hitch plates
• machines with tracks and big tires can reach the ground more easily.
• Standard safety equipment
• Operator’s station is conveniently located
• superior visibility
Large Skid-Steer Pallet Fork
Model | MCO5004048 | MCO5004060 |
Weight | 600 lbs | 650 lbs |
Width (Frame) | 48” | 48” |
Fork Length (Class 2 Tines) | 48” | 60” |
Lift Capacity | 7000 lbs | 7000 lbs |
Large Utility Loader Pallet Forks
Model | MCO5104008 | MCO5104048 | MCO5104060 |
Weight | 780 lbs | 900 lbs | 1020lbs |
Width (Frame) | 48” | 60” | 60” |
Fork Length (Class 3 Tines) | 48” | 48” | 60” |
Lift Capacity | 10,000 lbs | 10,000 lbs | 10,000 lbs |
