Skid Steer Hydraulic Telescopic Boom

This Hydraulic Boom is perfect for Contractors / Farmers for setting up trusses, beams, roofing and more. The Telescopic Boom turns your skid steer loader into a compact, high-performance crane without paying the cost of a boom truck. Our Telescopic boom has a Hydraulic single stage of 72 inches and a secondary manual adjusting stage allowing you to pin the boom into 5 different sections. This Telescopic Boom makes lifting and elevating as simple as moving one hydraulic lever. This boom is perfect for your skid steer with more maneuverability.

  • Fits Universal Quick Attach
  • Hydraulic hoses, couplers, and cylinder included
  • Metal Guide Rollers so boom can smoothly extend or retract
  • 3000Psi Hydraulic cylinder
  • Straight Clevis Included

675 Lbs

Dimensions

  • Overall Height 15″
  • Overall Width 47″
  • Fully Retracted 140″ (11.6 ft)
  • Cylinder Extracted 212″ (17.6 ft)
  • Cylinder and Secondary Adjustment Fully Extracted 260″ (21.6 ft)

Lifting Capacity

  • Fully Retracted 900Lbs
  • Cylinder Extended Only 800Lbs
  • Fully Extended (Cylinder and Manually Adjusted) 500Lbs

Tipping Load will vary by machine
