Utility Brush Grapple Bucket
Available for light weight Compact Tractors on the 20-40hp
Made of 3/8” Grade 80 steel for longer durability, easily move logs, stumps, large rocks and other brush or cumbersome materials on your job site with this grapple bucket. With two independent grapples powered by 4000 PSI hydraulic cylinders with cylinder guards, 1 1/4” pins, and all grease-able pivot pins, this attachment will provide the versatility you need to clear brush and debris from existing and freshly cleared timber with skid-steers up to 70HP. Narrow tine spacing optional.
| Model |
MCO9132066 |
MCO9132072 |
MCO9132078 |
| Weight |
740 lbs |
825 lbs |
840 lbs |
| Width |
66″ |
72″ |
78″ |
| Height |
22.5” |
22.5″ |
22.5″ |
| Depth |
37” |
37″ |
37″ |
| Tine Thickness |
3/8″ |
3/8″ |
3/8″ |
| Tine Spacing |
6 ½ ” |
6 ½ ” |
6 ½ ” |
| Grapple Open |
39” |
39” |
39” |
Construction Brush Grapple Bucket
Recommended for skid-steers and compact tractors up to 100HP and made of ½” T1 steel for long lasting durability, this construction grade brush grapple bucket has 2 independent 4000 PSI grapples with cylinder guards to stabilize tough loads during transport. All pins are 1 1/4” diameter and all pivot pins are grease-able. Optional narrow tine spacing available.
| Model | MCO9133066 | MCO9133072 | MCO9133078 | MCO9133084 |
| Weight |
890 lbs |
935 lbs |
1020 lbs |
1090 lbs |
| Width |
66″ |
72″ |
78″ |
84” |
| Height |
22.5” |
22.5″ |
22.5″ |
22.5” |
| Depth |
37” |
37″ |
37″ |
37” |
| Tine Thickness |
1/2″ |
1/2″ |
1/2″ |
1/2″ |
| Tine Spacing |
6 ½ ” |
6 ½ ” |
6 ½ ” |
6 ½ “ |
| Grapple Open |
39” |
39” |
39” |
39” |
We also offer Serrated Edge bolt as optional
